The Illinois BDE 2342 form plays a crucial role in ensuring that construction projects comply with environmental regulations, particularly those related to stormwater management. This form is part of the National Pollutant Discharge Elimination System (NPDES) and is specifically designed for projects that may impact water quality through stormwater runoff. It requires detailed information about the construction site, including its location, the nature of the construction activities, and the estimated duration of the project. Additionally, the form mandates a comprehensive description of the site’s environmental characteristics, such as soil types, wetland areas, and sensitive resources that could be affected by the construction. The contractor must certify the accuracy of the information provided, acknowledging the legal implications of submitting false data. Essential sections of the form address erosion and sediment control measures, stabilization practices, and structural practices that will be implemented to minimize environmental impact. Furthermore, it outlines the responsibilities of contractors in maintaining compliance with the outlined practices and the specific measures that will be taken to manage stormwater effectively, even after construction is completed. By fulfilling these requirements, the BDE 2342 form aims to protect Illinois waterways from pollution associated with construction activities.
Document Preview
|
|
Storm Water Pollution Prevention Plan |
|
||
Route |
|
Marked Rte. |
|
|
|
Section |
|
Project No. |
|
|
|
County |
|
Contract No. |
|
|
|
This plan has been prepared to comply with the provisions of the National Pollutant Discharge Elimination System (NPDES)Permit No. ILR10 (Permit ILR10), issued by the Illinois Environmental Protection Agency (IEPA) for storm water discharges from construction site activities.
I certify under penalty of law that this document and all attachments were prepared under my direction or supervision in accordance with a system designed to assure that qualified personnel properly gathered and evaluated the information submitted. Based on my inquiry of the person or persons who manage the system, or those persons directly responsible for gathering the information, the information submitted is, to the best of my knowledge and belief, true, accurate and complete. I am aware that there are significant penalties for submitting false information, including the possibility of fine and imprisonment for knowing violations.
Print Name |
|
Signature |
|
|
|
Title |
|
Date |
Agency
I.Site Description:
A.Provide a description of the project location (include latitude and longitude):
B.Provide a description of the construction activity which is the subject of this plan:
C.Provide the estimated duration of this project:
D. The total area of the construction site is estimated to be |
|
acres. |
|
|
The total area of the site estimated to be disturbed by excavation, grading or other activities is |
|
acres. |
||
E.The following is a weighted average of the runoff coefficient for this project after construction activities are completed:
F.List all soils found within project boundaries. Include map unit name, slope information, and erosivity:
G.Provide an aerial extent of wetland acreage at the site:
H.Provide a description of potentially erosive areas associated with this project:
I.The following is a description of soil disturbing activities by stages, their locations, and their erosive factors (e.g. steepness of slopes, length of slopes, etc):
Printed 6/1/2015 |
Page 1 of 8 |
BDE 2342 (Rev. 03/20/14) |
J.See the erosion control plans and/or drainage plans for this contract for information regarding drainage patterns, approximate slopes anticipated before and after major grading activities, locations where vehicles enter or exit the site and controls to prevent offsite sediment tracking (to be added after contractor identifies locations), areas of soil disturbance, the location of major structural and
K.Identify who owns the drainage system (municipality or agency) this project will drain into:
L.
The following is a list of General NPDES ILR40 permittees within whose reporting jurisdiction this project is located.
M.The following is a list of receiving water(s) and the ultimate receiving water(s) for this site. The location of the receiving waters can be found on the erosion and sediment control plans:
N.Describe areas of the site that are to be protected or remain undisturbed. These areas may include steep slopes, highly erodible soils, streams, stream buffers, specimen trees, natural vegetation, nature preserves, etc.
O.The following sensitive environmental resources are associated with this project, and may have the potential to be impacted by the proposed development:
Floodplain Wetland Riparian
Threatened and Endangered Species Historic Preservation
303(d) Listed receiving waters for suspended solids, turbidity, or siltation
Receiving waters with Total Maximum Daily Load (TMDL) for sediment, total suspended solids, turbidity or siltation
Applicable Federal, Tribal, State or Local Programs
Other
1.303(d) Listed receiving waters (fill out this section if checked above):
a.The name(s) of the listed water body, and identification of all pollutants causing impairment:
b.Provide a description of how erosion and sediment control practices will prevent a discharge of sediment resulting from a storm event equal to or greater than a
c.Provide a description of the location(s) of direct discharge from the project site to the 303(d) water body:
d.Provide a description of the location(s) of any dewatering discharges to the MS4 and/or water body:
2.TMDL (fill out this section if checked above)
a.The name(s) of the listed water body:
Printed 6/1/2015 |
Page 2 of 8 |
BDE 2342 (Rev. 03/20/14) |
b.Provide a description of the erosion and sediment control strategy that will be incorporated into the site design that is consistent with the assumptions and requirements of the TMDL:
c.If a specific numeric waste load allocation has been established that would apply to the project’s discharges, provide a description of the necessary steps to meet that allocation:
P.The following pollutants of concern will be associated with this construction project:
Soil Sediment
Concrete
Concrete Truck Waste
Concrete Curing Compounds
Solid Waste Debris
Paints
Solvents
Fertilizers / Pesticides
II.Controls:
Petroleum (gas, diesel, oil, kerosene, hydraulic oil / fluids) Antifreeze / Coolants
Waste water from cleaning construction equipment Other (specify)
Other (specify)
Other (specify)
Other (specify)
Other (specify)
This section of the plan addresses the controls that will be implemented for each of the major construction activities described in I.C. above and for all use areas, borrow sites, and waste sites. For each measure discussed, the Contractor will be responsible for its implementation as indicated. The Contractor shall provide to the ResidentEngineer a plan for the implementation of the measures indicated. The Contractor, and subcontractors, will notify the ResidentEngineer of any proposed changes, maintenance, or modifications to keep construction activities compliant with the Permit ILR10. Each such Contractor has signed the required certification on forms which are attached to, and are a part of, this plan:
A.Erosion and Sediment Controls: At a minimum, controls must be coordinated, installed and maintained to:
1.Minimize the amount of soil exposed during construction activity;
2.Minimize the disturbance of steep slopes;
3.Maintain natural buffers around surface waters, direct storm water to vegetated areas to increase sediment removal and maximize storm water infiltration, unless infeasible;
4.Minimize soil compaction and, unless infeasible, preserve topsoil.
B.Stabilization Practices: Provided below is a description of interim and permanent stabilization practices, including site- specific scheduling of the implementation of the practices. Site plans will ensure that existing vegetation is preserved where attainable and disturbed portions of the site will be stabilized. Stabilization practices may include but are not limited to: temporary seeding, permanent seeding, mulching, geotextiles, sodding, vegetative buffer strips, protection of trees, preservation of mature vegetation, and other appropriate measures. Except as provided below in II(B)(1) and II(B)(2), stabilization measures shall be initiated immediately where construction activities have temporarily or permanently ceased, but in no case more than one (1) day after the construction activity in that portion of the site has temporarily or permanently ceases on all disturbed portions of the site where construction will not occur for a period of fourteen (14) or more calendar days.
1.Where the initiation of stabilization measures is precluded by snow cover, stabilization measures shall be initiated as soon as practicable.
2.On areas where construction activity has temporarily ceased and will resume after fourteen (14) days, a temporary stabilization method can be used.
The following stabilization practices will be used for this project:
Preservation of Mature Vegetation |
Erosion Control Blanket / Mulching |
Vegetated Buffer Strips |
Sodding |
Protection of Trees |
Geotextiles |
Temporary Erosion Control Seeding |
Other (specify) |
Temporary Turf (Seeding, Class 7) |
Other (specify) |
Temporary Mulching |
Other (specify) |
Permanent Seeding |
Other (specify) |
Printed 6/1/2015 |
Page 3 of 8 |
BDE 2342 (Rev. 03/20/14) |
Describe how the stabilization practices listed above will be utilized during construction:
Describe how the stabilization practices listed above will be utilized after construction activities have been completed:
C.Structural Practices: Provided below is a description of structural practices that will be implemented, to the degree attainable, to divert flows from exposed soils, store flows or otherwise limit runoff and the discharge of pollutants from exposed areas of the site. Such practices may include but are not limited to: perimeter erosion barrier, earth dikes, drainage swales, sediment traps, ditch checks, subsurface drains, pipe slope drains, level spreaders, storm drain inlet protection, rock outlet protection, reinforced soil retaining systems, gabions, and temporary or permanent sediment basins. The installation of these devices may be subject to Section 404 of the Clean Water Act.
The following structural practices will be used for this project: |
|
Perimeter Erosion Barrier |
Rock Outlet Protection |
Temporary Ditch Check |
Riprap |
Storm Drain Inlet Protection |
Gabions |
Sediment Trap |
Slope Mattress |
Temporary Pipe Slope Drain |
Retaining Walls |
Temporary Sediment Basin |
Slope Walls |
Temporary Stream Crossing |
Concrete Revetment Mats |
Stabilized Construction Exits |
Level Spreaders |
Turf Reinforcement Mats |
Other (specify) |
Permanent Check Dams |
Other (specify) |
Permanent Sediment Basin |
Other (specify) |
Aggregate Ditch |
Other (specify) |
Paved Ditch |
Other (specify) |
Describe how the structural practices listed above will be utilized during construction:
Describe how the structural practices listed above will be utilized after construction activities have been completed:
D.Treatment Chemicals
Will polymer flocculants or treatment chemicals be utilized on this project:
Yes
No
If yes above, identifywhere and how polymer flocculants or treatment chemicals will be utilized on this project.
E.Permanent Storm Water Management Controls: Provided below is a description of measures that will be installed during the construction process to control volume and pollutants in storm water discharges that will occur after construction operations have been completed. The installation of these devices may be subject to Section 404 of the Clean Water Act.
1.Such practices may include but are not limited to: storm water detention structures (including wet ponds), storm water retention structures, flow attenuation by use of open vegetated swales and natural depressions, infiltration of runoff on site, and sequential systems (which combine several practices).
The practices selected for implementation were determined on the basis of the technical guidance in Chapter 41 (Construction Site Storm Water Pollution Control) of the IDOT Bureau of Design and Environment Manual. If practices other than those discussed in Chapter 41 are selected for implementation or if practices are applied to situations different from those covered in Chapter 41, the technical basis for such decisions will be explained below.
Printed 6/1/2015 |
Page 4 of 8 |
BDE 2342 (Rev. 03/20/14) |
2.Velocity dissipation devices will be placed at discharge locations and along the length of any outfall channel as necessary to provide a
Description of permanent storm water management controls:
F.Approved State or Local Laws:The management practices, controls and provisions contained in this plan will be in accordance with IDOT specifications, which are at least as protective as the requirements contained in the Illinois Environmental Protection Agency’s Illinois Urban Manual. Procedures and requirements specified in applicable sediment and erosion site plans or storm water management plans approved by local officials shall be described or incorporated by reference in the space provided below. Requirements specified in sediment and erosion site plans, site permits, storm water management siteplans or site permits approved by local officials that are applicable to protecting surface water resources are, upon submittal of an NOI, to be authorized to discharge under the Permit ILR10 incorporated by reference and are enforceable under this permit even if they are not specifically included in the plan.
Description of procedures and requirements specified in applicable sediment and erosion site plans or storm water management plans approved by local officials:
G.Contractor Required Submittals: Prior to conducting any professional services at the site covered by this plan, the Contractor and each subcontractor responsible for compliance with the permit shall submit to the Resident Engineer a Contractor Certification Statement, BDE 2342a.
1.The Contractor shall provide a construction schedule containing an adequate level of detail to show major activities with implementation of pollution prevention BMPs, including the following items:
•Approximate duration of the project, including each stage of the project
•Rainy season, dry season, and winter shutdown dates
•Temporary stabilization measures to be employed by contract phases
•Mobilization timeframe
•Mass clearing and grubbing/roadside clearing dates
•Deployment of Erosion Control Practices
•Deployment of Sediment Control Practices (including stabilized construction entrances/exits)
•Deployment of Construction Site Management Practices (including concrete washout facilities, chemical storage, refueling locations, etc.)
•Paving,
•Major planned stockpiling operations
•Timeframe for other significant
•Permanent stabilization activities for each area of the project
2.The Contractor and each subcontractor shall provide, as an attachment to their signed Contractor Certification Statement, a discussion of how they will comply with the requirements of the permit in regard to the following items and provide a graphical representation showing location and type of BMPs to be used when applicable:
Printed 6/1/2015 |
Page 5 of 8 |
BDE 2342 (Rev. 03/20/14) |
•Vehicle Entrances and Exits – Identify type and location of stabilized construction entrances and exits to be used and how they will be maintained.
•Material Delivery, Storage and Use – Discuss where and how materials including chemicals, concrete curing compounds, petroleum products, etc. will be stored for this project.
•Stockpile Management – Identify the location of both
•Waste Disposal – Discuss methods of waste disposal that will be used for this project.
•Spill Prevention and Control – Discuss steps that will be taken in the event of a material spill (chemicals, concrete curing compounds, petroleum, etc.)
•Concrete Residuals and Washout Wastes – Discuss the location and type of concrete washout facilities to be used on this project and how they will be signed and maintained.
•Litter Management – Discuss how litter will be maintained for this project (education of employees, number of dumpsters, frequency of dumpster
•Vehicle and Equipment Fueling – Identify equipment fueling locations for this project and what BMPs will be used to ensure containment and spill prevention.
•Vehicle and Equipment Cleaning and Maintenance – Identify where equipment cleaning and maintenance locations for this project and what BMPs will be used to ensure containment and spill prevention.
•Dewatering Activities – Identify the controls which will be used during dewatering operations to ensure sediments will not leave the construction site.
•Polymer Flocculants and Treatment Chemicals – Identify the use and dosage of treatment chemicals and provide the Resident Engineer with Material Safety Data Sheets. Describe procedures on how the chemicals will be used and identify who will be responsible for the use and application of these chemicals. The selected individual must be trained on the established procedures.
•Additional measures indicated in the plan.
III.Maintenance:
When requested by the Contractor, the Resident Engineer will provide general maintenance guides to the Contractor for the practices associated with this project. The following additional procedures will be used to maintain, in good and effective operating conditions, the vegetation, erosion and sediment control measures and other protective measures identified in this plan. It will be the Contractor’s responsibility to attain maintenance guidelines for any manufactured BMPs which are to be installed and maintained per manufacture’s specifications.
IV. Inspections:
Qualified personnel shall inspect disturbed areas of the construction site which have not yet been finally stabilized, structural control measures, and locations where vehicles and equipment enter and exit the site using IDOT Storm Water Pollution Prevention Plan Erosion Control Inspection Report (BC 2259). Such inspections shall be conducted at least once every seven (7) calendar days and within
Inspections may be reduced to once per month when construction activities have ceased due to frozen conditions. Weekly inspections will recommence when construction activities are conducted, or if there is 0.5” or greater rain event, or a discharge due to snowmelt occurs.
If any violation of the provisions of this plan is identified during the conduct of the construction work covered by this plan, the Resident Engineer shall notify the appropriate IEPA Field Operations Section office by email at: [email protected], telephone or fax within
The Incidence of
Printed 6/1/2015 |
Page 6 of 8 |
BDE 2342 (Rev. 03/20/14) |
Illinois Environmental Protection Agency
Division of Water Pollution Control
Attn: Compliance Assurance Section
1021 North Grand East
Post Office Box 19276
Springfield, Illinois
Additional Inspections Required:
V.Failure to Comply:
Failure to comply with any provisions of this Storm Water Pollution Prevention Plan will result in the implementation of a National Pollutant Discharge Elimination System/Erosion and Sediment Control Deficiency Deduction against the Contractor and/or penalties under the Permit ILR10 which could be passed on to the Contractor.
Printed 6/1/2015 |
Page 7 of 8 |
BDE 2342 (Rev. 03/20/14) |
Contractor Certification Statement
Prior to conducting any professional services at the site covered by this contract, the Contractor and every subcontractor must complete and return to the Resident Engineer the following certification. A separate certification must be submitted by each firm. Attach to this certification all items required by Section II.G of the Storm Water Pollution Prevention Plan (SWPPP) which will be handled by the Contractor/subcontractor completing this form.
Route |
|
Marked Rte. |
|
Section |
|
Project No. |
|
County |
|
|
Contract No. |
This certification statement is a part of SWPPP for the project described above, in accordance with the General NPDES Permit No. ILR10 issued by the Illinois Environmental Protection Agency.
I certify under penalty of law that I understand the terms of the Permit No. ILR 10 that authorizes the storm water discharges associated with industrial activity from the construction site identified as part of this certification.
In addition, I have read and understand all of the information and requirements stated in SWPPP for the above mentioned project; I have received copies of all appropriate maintenance procedures; and, I have provided all documentation required to be in compliance with the Permit ILR10 and SWPPP and will provide timely updates to these documents as necessary.
Contractor
Print Name |
|
Signature |
|
|
|
Title |
|
Date |
|
|
|
Name of Firm |
|
Telephone |
|
|
|
Street Address |
|
City/State/ZIP |
Items which this Contractor/subcontractor will be responsible for as required inSection II.G. of SWPPP:
Printed 6/1/2015 |
Page 8 of 8 |
BDE 2342a (Rev. 3/20/14) |
Form Specifications
| Fact Name | Fact Description |
|---|---|
| Purpose | The Illinois BDE 2342 form is used to create a Storm Water Pollution Prevention Plan (SWPPP) for construction projects. |
| Governing Law | This form complies with the National Pollutant Discharge Elimination System (NPDES) under Permit No. ILR10. |
| Certification Requirement | Individuals preparing the document must certify that the information is true and accurate under penalty of law. |
| Site Description | Details such as project location, construction activity, and estimated duration must be provided in the form. |
| Erosion Control | The form outlines necessary erosion and sediment control measures to minimize soil disturbance during construction. |
| Environmental Considerations | It requires identification of sensitive environmental resources that may be impacted, such as wetlands and endangered species. |
| Contractor Responsibilities | The contractor must submit a certification statement and a construction schedule detailing pollution prevention measures. |
| Stabilization Practices | Stabilization practices must be initiated immediately after construction activities cease to prevent soil erosion. |
Illinois Bde 2342: Usage Guidelines
Completing the Illinois BDE 2342 form is an essential step in ensuring compliance with environmental regulations related to storm water management for construction projects. The following steps will guide you through the process of filling out the form accurately and completely.
- Gather Required Information: Collect all necessary details regarding the project, including location, construction activities, and site specifics.
- Print the Form: Obtain a copy of the Illinois BDE 2342 form, which can typically be found on the Illinois Department of Transportation website or through your project’s engineering department.
- Fill Out Project Information: Start by entering the project location, including latitude and longitude, the nature of the construction activity, estimated project duration, and total area of the construction site.
- Detail Soil Information: List all soil types found within the project boundaries, including their characteristics like slope and erosivity.
- Describe Erosive Areas: Identify and describe any potentially erosive areas on the site, including details about soil disturbing activities and their locations.
- Identify Drainage Ownership: Specify who owns the drainage system that the project will drain into.
- List Environmental Resources: Document any sensitive environmental resources that may be impacted by the project, such as wetlands or endangered species habitats.
- Outline Pollution Control Measures: Describe the erosion and sediment control practices that will be implemented, including stabilization methods and structural practices.
- Include Treatment Chemicals: If applicable, indicate whether any treatment chemicals will be used and where they will be applied.
- Provide Permanent Storm Water Controls: Describe the permanent storm water management controls that will be installed after construction is complete.
- Review Local Laws: Ensure that the management practices align with local and state regulations regarding storm water management.
- Sign and Date: The person responsible for the plan must sign and date the form, certifying that all information provided is true and accurate.
After completing the form, review it thoroughly for accuracy. Ensure all required fields are filled out and that the information aligns with project specifications. Once finalized, submit the form as directed by your local environmental authority or as part of your project documentation.
Your Questions, Answered
What is the purpose of the Illinois BDE 2342 form?
The Illinois BDE 2342 form is designed to ensure compliance with the National Pollutant Discharge Elimination System (NPDES) Permit No. ILR10. This form outlines the Storm Water Pollution Prevention Plan (SWPPP) for construction site activities, helping to manage storm water discharges and minimize pollution during construction.
Who is responsible for preparing the BDE 2342 form?
The form must be prepared under the direction or supervision of qualified personnel. The individual responsible for its preparation must certify that the information provided is accurate and complete. This certification is a legal affirmation, and significant penalties exist for submitting false information.
What information is required in the site description section?
The site description section requires detailed information about the project location, including latitude and longitude, the nature of the construction activity, the estimated duration of the project, and the total area of the construction site. It also asks for details about soil types, wetland acreage, and potentially erosive areas.
What are the key erosion and sediment control measures outlined in the form?
The form emphasizes the importance of minimizing soil exposure, maintaining natural buffers around surface waters, and implementing various stabilization practices. These measures can include temporary and permanent seeding, mulching, and the use of erosion control blankets. Each contractor is responsible for the implementation of these controls.
What happens if construction activities temporarily cease?
If construction activities temporarily cease for fourteen days or more, stabilization measures must be initiated immediately. This ensures that disturbed areas are protected from erosion. In certain conditions, like snow cover, stabilization must occur as soon as practicable.
What are the structural practices mentioned in the BDE 2342 form?
Structural practices are designed to manage water flow and limit runoff from exposed areas. These may include perimeter erosion barriers, sediment traps, drainage swales, and temporary sediment basins. The goal is to divert flows from exposed soils and minimize pollutant discharge.
Are treatment chemicals allowed in the project?
Yes, the use of treatment chemicals, such as polymer flocculants, is permitted. If utilized, the form requires specific identification of where and how these chemicals will be applied to manage storm water effectively.
What are the contractor's responsibilities regarding submittals?
Before commencing work, the contractor must submit a Contractor Certification Statement and a detailed construction schedule. This schedule should outline major activities, pollution prevention measures, and timelines for implementation. It is crucial for maintaining compliance with the NPDES permit.
How does the BDE 2342 form ensure compliance with local laws?
The BDE 2342 form incorporates local laws and requirements into its management practices. It references approved sediment and erosion site plans, ensuring that the measures taken are at least as protective as those mandated by the Illinois Environmental Protection Agency's guidelines.
Common mistakes
-
Incomplete Site Description: Failing to provide a comprehensive description of the project location, including latitude and longitude, can lead to misunderstandings about the site. This information is crucial for regulatory bodies to assess environmental impacts accurately.
-
Omitting Erosion Control Measures: Neglecting to detail the erosion control practices that will be implemented can result in significant penalties. It's essential to outline specific measures to minimize soil disturbance and manage runoff effectively.
-
Incorrect Pollutant Identification: Listing incorrect or incomplete pollutants associated with the construction project can mislead regulatory agencies. It's vital to accurately identify all potential pollutants, such as soil, sediment, and chemicals, to ensure compliance with environmental standards.
-
Failure to Include Contractor Certifications: Not attaching the required Contractor Certification Statement can delay project approval. Each contractor must certify their understanding of the permit requirements and their commitment to follow them throughout the project.
-
Neglecting to Describe Permanent Storm Water Controls: Omitting details about the permanent storm water management controls that will be installed after construction can lead to compliance issues. It's important to specify how these controls will function to manage stormwater discharges effectively.
Documents used along the form
When dealing with the Illinois BDE 2342 form, it is essential to understand that several other documents and forms often accompany it. These documents help ensure compliance with environmental regulations and support the overall stormwater management strategy. Below are five key forms that are frequently used alongside the BDE 2342.
- Contractor Certification Statement (BDE 2342a): This document certifies that the contractor understands and agrees to comply with the requirements outlined in the stormwater pollution prevention plan. It includes a commitment to implement best management practices (BMPs) to minimize environmental impact during construction.
- Notice of Intent (NOI): The NOI is a formal request to obtain coverage under the NPDES permit. It provides information about the project and serves as a notification to the Illinois Environmental Protection Agency (IEPA) that construction activities will commence, thus requiring stormwater management practices.
- Stormwater Management Plan (SWMP): This comprehensive plan outlines the strategies for managing stormwater runoff throughout the construction process. It includes details on erosion and sediment control measures, as well as long-term management practices post-construction.
- Erosion and Sediment Control Plan (ESCP): The ESCP is a detailed plan that specifies how to prevent soil erosion and manage sediment during construction activities. It includes design features and practices that will be implemented to protect water quality.
- Site Inspection Reports: These reports document regular inspections of the construction site to ensure compliance with the stormwater management plan. They help identify any issues that may arise and outline corrective actions to maintain compliance with environmental regulations.
Understanding these accompanying documents is crucial for ensuring a successful and compliant construction project. Each form plays a vital role in protecting the environment while facilitating necessary development. By adhering to these guidelines, contractors can contribute to sustainable practices and minimize the impact of construction activities on local waterways.
Similar forms
The Illinois BDE 2342 form is crucial for managing stormwater pollution at construction sites. Several other documents serve similar purposes, ensuring compliance with environmental regulations. Here are five documents that share similarities with the Illinois BDE 2342 form:
- Stormwater Management Plan (SWMP): Like the BDE 2342, the SWMP outlines strategies to manage stormwater runoff, including erosion and sediment control measures. Both documents aim to prevent pollution during construction activities.
- National Pollutant Discharge Elimination System (NPDES) Permit Application: This application is necessary for obtaining permission to discharge pollutants. It requires detailed information about the project, similar to the site descriptions found in the BDE 2342.
- Site Erosion Control Plan: This plan focuses on controlling soil erosion at construction sites. It details practices to minimize soil disturbance, paralleling the erosion control measures outlined in the BDE 2342.
- Construction Site Stormwater Runoff Control Plan: This document specifies the techniques and practices to manage stormwater runoff from construction sites. It aligns with the goals of the BDE 2342 in protecting water quality during construction.
- Environmental Impact Assessment (EIA): An EIA evaluates the potential environmental effects of a proposed project. It includes considerations for water quality and erosion, similar to the impact assessments included in the BDE 2342.
Dos and Don'ts
When filling out the Illinois BDE 2342 form, it's crucial to be thorough and accurate. Here’s a list of essential dos and don'ts to guide you through the process.
- Do provide complete and accurate information for each section, ensuring that all descriptions are clear.
- Do include latitude and longitude for the project location as required in the site description.
- Do review the form for any missing signatures or dates before submission.
- Do consult with qualified personnel to verify the information submitted is true and complete.
- Don't leave any sections blank; if a section does not apply, clearly indicate that.
- Don't submit the form without ensuring compliance with all relevant local and state regulations.
By following these guidelines, you can help ensure a smooth submission process for the Illinois BDE 2342 form.
Misconceptions
Understanding the Illinois BDE 2342 form is essential for anyone involved in construction projects that may impact stormwater management. However, several misconceptions often arise regarding this form. Here are nine common misunderstandings:
- It is only for large construction projects. Many believe that the BDE 2342 form applies only to large-scale developments. In reality, any construction project that disturbs soil may require this form, regardless of size.
- Submitting the form is optional. Some think that filing the BDE 2342 is a choice. However, it is a legal requirement for compliance with the National Pollutant Discharge Elimination System (NPDES) permit.
- Once submitted, no further action is needed. People often assume that after submitting the form, they can forget about it. In fact, ongoing compliance and monitoring are necessary throughout the construction process.
- Only engineers need to fill it out. While engineers play a significant role, the form requires input from various professionals, including contractors and environmental specialists, to ensure accurate information.
- It only addresses water quality. Many think the BDE 2342 focuses solely on water quality. However, it also considers soil erosion, sediment control, and overall environmental protection.
- There are no penalties for inaccuracies. Some believe that minor errors on the form won't have consequences. In truth, submitting false information can lead to significant fines and legal repercussions.
- It is a one-size-fits-all document. Many assume that the BDE 2342 can be filled out with generic information. Each project is unique, and the form must reflect specific site conditions and practices.
- All required information is straightforward. People often think that the information needed is simple. However, detailed descriptions of soil types, erosion factors, and environmental resources are crucial and can be complex.
- It is only concerned with immediate impacts. Some believe the form only addresses short-term effects of construction. In reality, it also considers long-term impacts on water quality and ecosystem health.
Addressing these misconceptions can help ensure that construction projects proceed smoothly and in compliance with environmental regulations. Understanding the BDE 2342 form is a step towards responsible construction practices.
Key takeaways
Here are key takeaways for filling out and using the Illinois BDE 2342 form:
- Ensure compliance with the National Pollutant Discharge Elimination System (NPDES) Permit No. ILR10.
- Provide accurate project details, including location, construction activities, and estimated duration.
- Clearly state the total area of the construction site and the area expected to be disturbed.
- Identify all soils within the project boundaries, including slope information and erosivity.
- List sensitive environmental resources that may be affected by the project.
- Detail erosion control measures and stabilization practices to be implemented during and after construction.
- Include descriptions of structural practices to limit runoff and manage stormwater discharges.
- Document any treatment chemicals used and their application locations.
- Submit a Contractor Certification Statement before starting any work on site.
- Attach a detailed construction schedule that outlines major activities and pollution prevention measures.
